مركز الميكنة متعددة الوظائف Fanuc a-D21MiB

This 3-axis FANUC α-D21MiB was manufactured in 2022. It features a spindle speed of 10,000 rpm and a maximum tool storage capacity of 21 tools. The machine offers impressive X-axis travel of 500 mm, Y-axis travel of 400 mm, and Z-axis travel of 330 mm. If you are looking to get high-quality machining capabilities, consider the FANUC α-D21MiB vertical machining centre we have for sale. Contact us for further details.
Location: DE
Control Brand: FANUC
Control Model: Series 31i-MODEL B
Spindle Power: 4 kW
Table Load: 300 kg
Spindle Taper: BBT30
Spindle Load / Torque (High Torque 10,000 rpm): 80 Nm (1 min), 13.6 Nm (continuous)
Spindle Load / Power: 14.2 kW (1 min), 4 kW (continuous)
Distance from Spindle Nose to Table: 250 - 580 mm (with HC100)
Tool Storage Capacity (ATC): 21 tools
Tool Change Time (Cut-to-Cut): 1.6 s
Max. Tool Mass: 3 kg
Rapid Traverse (X/Y/Z): 54 m/min
Programmable Cutting Feedrate: 30,000 mm/min
Acceleration X/Y/Z: 1.4G / 1.0G / 1.6G
Air Pressure / Flow Consumption: 0.35 - 0.55 MPa / 150 L/min
Positioning Accuracy (Bidirectional)
Repeatability (Bidirectional)
additional available accessories
* Transformer 20 kVA/IP23
* High Column 100 mm
* Top Cover High Column Parts HC100
* Festo G3/8" Push-in Fitting 12mm for CTS Sealing
* Festo 12mm Blanking Plug for CTS Sealing
